Steel Frame Products

Single storey projects delivered to site within 6 weeks and double storey within 8 weeks!

Benefits for the Designer/Architect

Steel Frame Solutions frames are the smart choice for Australia's leading designers and builders. Steel frames are easy and fast to erect, and strong and lightweight. Steel Frame Solutions steel trusses offer excellent spanning capabilities, so both designers and home owners can enjoy newfound freedom with large open space contemporary designs.



We constantly seek innovations in technology and also in the solutions we deliver, our design skills and tools are so highly advanced we can manufacture our products to suit almost any floor plan or construction style. Consistent product quality and a high level of accuracy provide designers with assurance of strong, versatile and attractive designs that are engineered for life.


Steel Frame Solutions frames are compatible with all other building products, internal and external linings, and they are well suited for steep or sloping sites. Steel frames are ideal for termite infected areas; they are non-combustible and are 100% recyclable and environmentally friendly.

Download Brochure

STUDS

Stud 70 x 0.55

The vertical structural member of a wall panel to which internal linings and/or external cladding materials are fixed. Service holes are provided for following trades.

Download CAD Files

Stud 75 x 0.55

The vertical structural member of a wall panel to which internal linings and/or external cladding materials are fixed. Service holes are provided for following trades.

Download CAD Files

Stud 75 x 0.75

The vertical structural member of a wall panel to which internal linings and/or external cladding materials are fixed. Service holes are provided for following trades.

Download CAD Files

Stud 90 x 0.55

The vertical structural member of a wall panel to which internal linings and/or external cladding materials are fixed. Service holes are provided for following trades.

Download CAD Files

Stud 90 x 0.75

The vertical structural member of a wall panel to which internal linings and/or external cladding materials are fixed. Service holes are provided for following trades.

Download CAD Files

TRUSS MATERIAL

Truss Material C/75 x 0.75

This material is used to manufacture trusses and jack rafters. C section can also be used for hip corners and trimming within the roof space.

Download CAD Files

Truss Material C/75 x 1.0

This material is used to manufacture trusses and jack rafters. C section can also be used for hip corners and trimming within the roof space.

Download CAD Files

BATTENS

Ceiling Batten 0.42

Ceiling battens are versatile and easy to use, providing strength, lightness and rigidity with low cost. Fasten to steel truss with #10-16x16 hex screw. It is used to support ceiling lining.

Download CAD Files

Roof Batten 0.55

Steel Frame Solutions battens are manufactured from quality, high strength Zincalume steel which is approximately ten times more resistant to corrosion than galvanised products.

Download CAD Files

LINTEL

Lintel 105x35 x 1.5

A horizontal structural member of a wall panel that spans over an opening (such as a window or door) to transfer superimposed loads to jamb studs at each side of the opening.

Download CAD Files

Lintel 200x35 x 1.0

A horizontal structural member of a wall panel that spans over an opening (such as a window or door) to transfer superimposed loads to jamb studs at each side of the opening.

Download CAD Files

Lintel 200x35 x 1.5

A horizontal structural member of a wall panel that spans over an opening (such as a window or door) to transfer superimposed loads to jamb studs at each side of the opening.

Download CAD Files

OMEGA NOGGING

Omega Nogging 0.55 x 6100

A continuous horizontal member fixed through holes at stud mid height, to stiffen wall panels.

Download CAD Files

TRIM ANGLE

Trim angle 35x35 x 1.0

A 90* angle 35x35mm used to form corners and general trimming.

Download CAD Files

PLATES

Plate 70x35 x 0.75 (non-structural)

A horizontal member of a wall panel fixed across the bottom of studs. Fasteners are fixed down through the bottom plate to fix the wall panel to the floor. Also used for solid noggings, heads and sills of openings and top plate for non-load bearing walls.

Download CAD Files

Plate 75x35 x 0.75 (non-structural)

A horizontal member of a wall panel fixed across the bottom of studs. Fasteners are fixed down through the bottom plate to fix the wall panel to the floor. Also used for solid noggings, heads and sills of openings and top plate for non-load bearing walls.

Download CAD Files

Plate 70x65 x 1.0 (structural)

A horizontal structural member of a wall panel fixed across the top of studs to carry roof load.

Download CAD Files

Plate 75x65 x 1.0 (structural)

 A horizontal structural member of a wall panel fixed across the top of studs to carry roof load.

Download CAD Files

Plate 90x65 x 1.0 (structural)

 A horizontal structural member of a wall panel fixed across the top of studs to carry roof load.

Download CAD Files

Plate 90x35 x 0.75 (non-structural)

A horizontal member of a wall panel fixed across the bottom of studs. Fasteners are fixed down through the bottom plate to fix the wall panel to the floor. Also used for solid noggings, heads and sills of openings and bottom plate for non-load bearing walls.

Download CAD Files

ACCESSORIES

Apex Plates

Apex plates are used at the apex of the truss where multiple chords and webs meet, providing a high load bearing connection.

Grommets – electrical

Electrical grommets are installed before wiring to protect cables from the sharp edges of the service hole.

Grommets – plumbing

Plumbing grommets assist with preventing noise from water hammer and isolate copper pipes form the steel frame.

Omega Noggin Clips

A steel clip used to secure strip nogging through service holes to studs.

Brace Tensioner set

A component fixed to strap bracing that is tightened or loosened to plumb and permanently brace a wall panel.

Internal Wall Bracket

Internal wall (hitch) brackets are designed to provide lateral support to internal walls whilst allowing vertical movement of the roof structure.

Bath Channel

An additional structural member of a wall panel set into studs to provide a recess for a bath.
